JBD Smart Bluetooth BMS 4S-8S 100A150A 200Acurrent For DIY lithium ion LiFePo4 Battery pack

Sold Out
Unit Price
Shipping calculated at checkout.

JBD Smart BMS 4S-8S JBD BMS 4S 100A

- +

EU have battery Warehouse 5-7 days delivery!

Terence crema
Mail : 206projectsound@gmail.com
Per mercato italiano, assistenza, installazione


If you need to purchase a BMS, please send us a message, and we will tailor a BMS solution for you and provide the best price!


 ● Package- BMS * Bluetooth * Balance Wires

● 3S 4S BMS for Li-ion/Lifepo4 battery

● Continuous Current 100-200A / Balance Current 1-2A

● Size 192±2*105±0.5*20±1 mm

● Doesn't Support Series Connection

● Various Protection Functions for Charging and Discharging

● "H" Heating Function

● SOC calculation and learning ability

● 1 Internal/2 External Temperature Sensors (Detect battery temperature)

● Support Bluetooth(Gift), UART and RS485

Bluetooth link for Phone-Xiaoxiang BMS

Download link-IOS (cannot be set): Search in the APP STORE

Download link-Andriod (can be set): https://www.pgyer.com/Bzt1

Uart Link for Computer :http://www.jiabaida.com/uploads/soft/xiaoxiangBMS.zip?spm=5261.im.0.0.7e0e4edfdzhzxA&file=xiaoxiangBMS.zip

● Support UART Communication, UART(Bluetooth) and RS485 can work together.

● Used for Small Energy Storage Battery, Street Lamp, 12V Lead-Acid Replacement Lithium battery

● User Manual-Customer Service, which can be sent by Email.

Customer Reviews

Based on 1 review
Joe Schmidt
Works as a BMS, but no RJ45 CANBUS as advertised

Works fine as a standalone BMS however doesn't plug into an RJ45 wired canbus network as advertised in the diagram on the web page. so while it works it doesn't function in the ecosystem it was intended to.
